More Than A Trampoline
The Strongest Trampoline Frame
Magic and Creative Trampolines
Specifications & Packaging & Manuals
| H1 | H2 | H3 | Ø1 | Ø2 | |
|---|---|---|---|---|---|
| 8FT | 2.85m | 1.85m | 0.89m | 2.45m | 2.05m |
| 10FT | 2.85m | 1.85m | 0.89m | 3.05m | 2.55m |
| 12FT | 2.85m | 1.85m | 0.89m | 3.65m | 3.15m |
| 14FT | 2.85m | 1.85m | 0.89m | 4.35m | 3.75m |
| H1 | Height of SPARK Trampoline |
| H2 | Height of Safety Net |
| H3 | Height of Jump Mat |
| Ø1 | Diameter of SPARK Frame |
| Ø2 | Diameter of Jump Mat |
The recommended minimum clearance space around your Spark trampoline and accessories is at least 1.5m. And more space is required for Swing Sets and Hanging Sets.
| Spark SW - 8FT | |
|---|---|
| Max user weight | 120kg |
| No. of springs | 48 |
| Trampoline weight | 78kg |
| Package | |
| Box 1 (x1) (L*W*H) | 125cm * 38cm * 21cm |
| Box T (x3) (L*W*H) | 102cm * 44cm * 9cm |
| Spark SW - 10FT | |
|---|---|
| Max user weight | 150kg |
| No. of springs | 64 |
| Trampoline weight | 100kg |
| Package | |
| Box 1 (x1) (L*W*H) | 126cm * 46cm * 25cm |
| Box T (x4) (L*W*H) | 102cm * 44cm * 9cm |
| Spark SW - 12FT | |
|---|---|
| Max user weight | 150kg |
| No. of springs | 80 |
| Trampoline weight | 126kg |
| Package | |
| Box 1 (x1) (L*W*H) | 126cm * 46cm * 33cm |
| Box T (x5) (L*W*H) | 102cm * 44cm * 9cm |
| Spark SW - 14FT | |
|---|---|
| Max user weight | 150kg |
| No. of springs | 96 |
| Trampoline weight | 152kg |
| Package | |
| Box 1 (x1) (L*W*H) | 126cm * 39cm * 38cm |
| Box T (x6) (L*W*H) | 102cm * 44cm * 9cm |
